| Ask Lasest Price | |
| Model Number : | DCA501 |
| Brand Name : | LI Solar |
| Supply Ability : | 1000 Pack/Packs per Day |
| Price : | Negotiation |
MODEL | DCA501 | DCA502 | DCA503 | DCA504 | DCA1002 | ||||
Nominal Voltage | 51.2V | 51.2V | 51.2V | 51.2V | 51.2V | ||||
Energy | 5.12KWH | 10.24KWH | 15.36KWH | 20.48KWH | 20.48KWH | ||||
Nominal Capacity | 100Ah | 100Ah*2 | 100Ah*3 | 100Ah*4 | 200Ah*2 | ||||
Charging Limit Voltage | 58.4V | ||||||||
Working Voltage | 44.8V-58.4V | ||||||||
Standard Charging Current | 40A | 40A | 80A | 80A | 80A | ||||
Max.Charging Current | 100A | 100A | 200A | 200A | 200A | ||||
Discharging End-off Voltage | 44.8V | ||||||||
Standard discharge current | 40A | 40A | 80A | 80A | 80A | ||||
Max.Discharge Current | 100A | 100A | 200A | 200A | 200A | ||||
Battery Cell Type | LFP 3.2V 50Ah | ||||||||
Communication | CAN2.0/RS485/RS232 | ||||||||
Case Material | Cold-Roll Steel Sheets | ||||||||
Dimension | 695*505*321mm | 695*505*513mm | 695*505*704.5mm | 695*505*895mm | 695*525*825mm | ||||
Battery Weight | 68kg | 127kg | 186kg | 245kg | 235kg | ||||
Operating Temperature Range | Charging:0ºC-45ºC | ||||||||
Discharging:-20ºC-60ºC | |||||||||
Benefits for Villa Living:
* Personalized Energy Solutions: Tailor your energy storage to
align perfectly with the unique requirements of your villa,
ensuring a bespoke solution that complements your luxurious
lifestyle.
* Optimized Interior Spaces: Embrace a clutter-free villa
environment with our space-efficient design, allowing you to
maximize every inch without sacrificing energy storage capacity.
* Future-Proof Scalability: Grow confidently with our modular
design, providing a scalable solution that seamlessly adapts to the
evolving energy needs of your expanding villa.
|
|
